(2) Install it to the GLT400.
* Pay attention to the protrusions when direct-connecting.
● Please direct-connect the extension terminal bases carefully so as not to bend the protrusions next to
the connector.
● Please handle the GLT400 in a horizontal state until the extension terminal bases are fixed with the
connecting plate.
(3) Assemble the spacer.
Place the GLT400 to which the expansion terminal base is attached on the spacer without rattling.
Spacer
(4) Attach it with the supplied screws.
* Recommended tightening torque: 14 kgf/cm
M4×6 flat screw
Spacer
CHAPTER 2 Checks and Preparation
Spacer
2-5
