GLT400 operation
Capturing start/stop and simple control can be performed.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
Selection Item
(1) Start/Stop
(2) Sampling Interval
(3) Alarm Clear
(4) Date Setting
(5) Language change
(6) Demo data
(7) Initialize operation settings
(8) Initialize network settings
(9) Restart
(10) Command send/read
Starts and stops capturing on the GLT400. It takes a few seconds for the status to be reflected.
Changes the sampling interval. When set to the sampling interval that cannot be changed, it returns
to the original set value after a few seconds.
Performs alarm clear. It is available only when the alarm setting is set to "Hold alarm".
Sets the clock of the GLT400. If the communication environment is poor, the set time may be shifted.
Changes the language used in the GLT400 and the language displayed on the WEB server. When
the language of the GLT400 is changed, it affects the language display of CSV data.
Enables demo data display. The demo data setting returns to Off when the power of the GLT400 is
turned off and then on again.
Initializes the operation settings. The displayed contents after initialization may not match. In that
case, reload the WEB screen.
Initializes the network settings. If initialized, the network may be disconnected. Therefore, carry out
with great care.
Forcibly restart the GLT400. Perform this only when the condition of the GLT400 becomes unstable.
The GLT400 is forcibly restarted, so carry out with great care.
Sends and receives the interface commands of the GLT400. The GLT400 cannot send or receive
the commands that process binary, such as receiving binary data. Be sure to send the commands
separately for each command.
The interface command specification is included in the SDK (Software Development Kit) of the
GLT400. If you want to get the SDK, please contact us from our website.
