CHAPTER 5 Specification

5.3 List of Error Codes

If an error occurs in the GLT400, the POWER LED is lit in red and a buzzer sounds. To check the error
description, connect the GLT400 Setting App. The error codes are listed below.
Operation and setting errors
Code number
101 Ring capturing condition error
102 Backup condition error
103 - Ditto -
105 Invalid trigger condition
(Start trigger)
106 Invalid trigger condition
(Stop trigger)
107 Disk full
108 Disk error
109 Backup condition error
111 Backup condition error
112 System error
113 Backup condition error
114 Backup condition error
115 Backup condition error
117 Invalid AMP configuration
118 Setting file error
119 Capturing error
120 Disk error
122 Backup condition error
123 Disk error
125 Easy Connection (WPS) failure
127 SD CARD write protect
128 Capturing condition error
130 SD CARD replacement error
131 Disk error
132 E-mail error
133 Backup operation error
134 Invalid trigger condition (Start trigger)
135 Invalid trigger condition (Stop trigger)
Disk error
If a disk error has occurred, try the following:
● Turn on the power of the GLT400 again
● Disk initialization
● Change to another disk (for SD CARD)
No.
1001 This is an error that cannot be processed.
1002 The target file or directory does not exist.
1003 The hardware may have failed. Please contact us.
1005 The internal memory or SD CARD may have failed.
1008 There is a problem in the internal memory or the SD CARD.
1009 Please contact us.
1012 The memory capacity within the system is insufficient.
1013 It is write-protected. Check the write-protect switch of the SD CARD.
5-10
Error
The number of ring capturing points exceeds the capacity of the capturing
destination.
When saving in CSV format, specify a sampling interval slower than 100 ms.
- Ditto -
There are no valid channels for the trigger start condition. Change the
trigger condition.
There are no valid channels for the trigger stop condition. Change the
trigger condition.
The disk capacity is full.
Disk input and output error has occurred.
The data capturing destination and backup destination cannot be
specified on the same media.
The backup destination folder cannot be created.
Memory capacity is insufficient.
The relay capturing setting is On. Backup is not performed.
Backup is not performed when external sampling is enabled.
The remaining capacity of the capturing media is insufficient. If you want
to delete the captured files when the backup is successful, you need at
least twice the free space as it was when the relay was set.
Because the current AMP configuration and the AMP configuration in the
setting file are different, the AMP is not set.
The contents of the setting file are incorrect.
During capturing, the capturing start command was received again.
Capturing destination error
The ring capturing setting is On. Backup is not performed.
Disk remaining capacity is not enough.
Wireless LAN Easy Connection (WPS) failed.
The SD CARD is write-protected.
Capturing cannot be started in REMOTE mode.
The SD CARD cannot be replaced.
There is no SD CARD for the capturing destination.
E-mail send failed.
Backup failed.
There is no valid start trigger condition.
There is no valid stop trigger condition.
Description
Description
