CHAPTER 3 Operation and Function
Status
The device name and capturing status can be checked.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
Selection Item
(1) Device name
(2) Capturing status
(3) Capturing start time
(4) Trigger time
(5) Number of capturing points
(6) Number of channels
(7) Sampling interval
(8) Capturing file name
(9) Capturing capacity
3-26
Displays the device name. To change the device name, use the GLT400 Setting App on the PC.
Displays the capturing status.
Displays the capturing start time. It is displayed only when capturing started.
Displays the trigger time. It is displayed only when capturing started.
Displays the number of capturing points. Refresh the screen on the web browser each time
because it is not refreshed automatically.
Displays the number of channels included in the GLT400.
Displays the sampling interval.
Displays the capturing file name or the folder name.
Displays the capturing capacity.
Description
