2.12 Mounting the SD CARD

•
When the SD CARD is inserted, make sure that the card is not locked. If locked, the data cannot be
captured.
•
Do not remove the SD CARD while accessing the SD CARD (When the SD ACCESS LED is lit in "green").
The captured data may be damaged.
•
When inserting the large capacity SD CARD, it may take some time to recognize it.
How to insert the SD CARD (SD CARD)
Insert the SD CARD into the SD CARD slot.
When the optional wireless LAN unit is installed, the SD CARD cannot be inserted.
(1) Remove the SD CARD protective cover.
* Store the protective cover in the holding space.
Holding space
(2) Insert the SD CARD until it clicks and is locked.
* Make sure that the SD CARD is not locked.
* Make sure that the SD CARD is not
locked.
(3) Insert and close the protective cover into the upper hole and lower hole for the SD CARD protective
cover.
Protective cover
SD CARD
Protective cover
CHAPTER 2 Checks and Preparation
2-27
