CHAPTER 3 Operation and Function
(6) Wireless LAN Easy Connection (WPS)
When the wireless LAN unit (B-568) (option) is connected, the wireless LAN can be easily connected by
using the Wireless LAN Easy Connection (WPS) function.
* To use this function, the GLT400 must be in the Free running (capturing stopped) status.
STAND-ALONE mode
Connect the separately sold wireless LAN router (wireless LAN base unit) to the GLT400 (wireless LAN
remote unit).
Check in advance whether the wireless LAN router you will use has a function equivalent to WPS.
Free running
(capturing stopped)
Press and hold the [FUNCTION] key
Press the WPS button on the wireless
LAN base unit
* The following image of the wireless
LAN base unit is an example.
Easy Connection (WPS) is in progress
Pi Pi Pi
Easy Connection (WPS) was
successful
IP address automatic acquisition
Bi - Bi - - -
Easy Connection (WPS) failed
3-18
