CHAPTER 5 Specification

Standard terminal B-564/Screwless terminal B-564SL

Item
Number of Standard
input channels terminal
Screwless
terminal
Input terminal Standard
type terminal
Screwless
terminal
Input method
Scan speed
Measurement ranges
Measurement accuracy
(23°C ±5°C)
• When 30 minutes or more
have elapsed after power was
switched on
• Sampling 1 s/20 ch
• Filter ON (10)
• GND connected
5-4
20 channels (up to 10 units (200 channels) can be connected to GLT400)
* Between GLT400 and terminal and between terminals can be direct-connected or with an
expansion terminal connection cable (sold separately).
20 channels (up to 10 units (200 channels) can be connected to GLT400)
* Between GLT400 and terminal and between terminals can be direct-connected or with an
expansion terminal connection cable (sold separately).
M3 screw type terminals (Rectangular flat washer)
Screwless terminal
Photo MOS relay scanning system
All channels isolated, balanced input
* Terminal b to be used to connect the Resistance bulb is shorted within all channels.
10 ms/1 ch maximum
Voltage: 20, 50, 100, 200, 500 mV; 1, 2, 5, 10, 20, 50, 100 V; 1-5 V F.S.
Temperature
Thermocouples: K, J, E, T, R, S, B, N, C (WRe5-26)
Resistance bulb: Pt100, JPt100, Pt1000 (IEC751)
Temperature range: 100°C, 500°C, 2000°C
(In the case of Fahrenheit: 150°F, 750°F, 3000°F)
Humidity: 0 to 100% (voltage 0 to 1 V scaling conversion) fixed
Voltage: 0.1% of F.S.
Temperature
•
Thermocouple
Thermocouple Measurement Temperature Range (°C)
R/S
R : 300 < TS ≤ 1600℃
B
K
E
T
J
N
C (W)
Reference contact compensation accuracy
* Thermocouple diameters T - K: 0.32 φ, others: 0.65 φ
•
Resistance bulb
Measurement Temperature Range
Type
Pt100 -200 to 850℃ (FS=1050℃)
JPt100 -200 to 500℃ (FS=700℃)
Pt1000 -200 to 500℃ (FS=700℃)
* 3-wire system
Description
0 ≤ TS ≤ 100℃
100 < TS ≤ 300℃
S : 300 < TS ≤ 1760℃
400 ≤ TS ≤ 600℃
600 < TS ≤ 1820℃
-200 ≤ TS ≤ -100℃
-100 < TS ≤ 1370℃
-200 ≤ TS ≤ -100℃
-100 < TS ≤ 800℃
-200 ≤ TS ≤ -100℃
-100 < TS ≤ 400℃
-200 ≤ TS ≤ -100℃
-100 < TS ≤ 100℃
100 < TS ≤ 1100℃
-200 ≤ TS < 0℃
0 ≤ TS ≤ 1300℃
0 ≤ TS ≤ 2000℃
(°C)
Measurement Accuracy
±5.2℃
±3.0℃
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +2.0℃)
±3.5℃
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +1.0℃)
± (0.05% of rdg +2.0℃)
± (0.05% of rdg +1.0℃)
± (0.1% o f rdg +1.5℃)
± (0.1% o f rdg +0.5℃)
±2.7℃
±1.7℃
± (0.05% of rdg +1.0℃)
± (0.1% o f rdg +2.0℃)
± (0.1% o f rdg +1.0℃)
± (0.1% o f rdg +1.5℃)
±0.5℃
Measurement
Applied current
Accuracy
1 mA ±1.0℃
1 mA ±0.8℃
0.3 mA ±0.8℃
