CHAPTER 5 Specification
5.1 Standard Specifications

Standard specifications (GLT400)

Number of analog terminal units installed
Analog terminal unit type
Backup function
Clock accuracy (23°C environment)
Operating environment
Withstand voltage
Power supply
Power consumption
External dimensions
(approx.)
[W x D x H]
(GLT400 + terminal
installed)
Weight (approx.) * 1
(Main unit + terminal
installed)
Others
*1: AC adapter not included.
5-2
Item
Up to 10 units (200CH)
• Standard terminal
• Withstand high-voltage high-precision terminal
• Screwless terminal
Setting conditions: EEPROM / Clock: Lithium secondary battery
±0.002% (approx. 50 seconds per month)
-20 to 60°C (Supplied AC adapter: 0 to 45°C), 5 to 85% RH
(If a USB PD is used as the power supply, it depends on the power supply
Standard terminal/ Between input channel and GND terminal: 350Vp-p 1 minute
Screwless terminal Between input terminals: 350 Vp-p 1 minute
Withstand high- Between input channel and GND terminal: 2300VACrms 1 minute
voltage high- Between input terminals: 600 Vp-p
precision terminal
• AC adapter: 100 to 240V AC / 50 to 60 Hz
• DC input: 8.5 to 24V DC (maximum 26.4V)
• USB power supply: USB PD compatible, external USB PD compatible battery
AC power consumption (when using the supplied AC adapter)
No.
DC current consumption
No.
Standard terminal 187.5 × 183 × 65.5 mm (excluding protrusions)
Withstand high- 187.5 × 183 × 73.4 mm (excluding protrusions)
voltage high-
precision terminal
Screwless terminal 187.5 × 183 × 65.5 mm (excluding protrusions)
Withstand high- 1090 g
voltage high-
precision terminal
Others 1120 g
Screwless terminal 1020 g
Vibration proof: Automobile parts Type 1 Class A equivalent
Buzzer (Key, etc.)
specifications.)
Power supply
1 AC100V
AC240V
DC voltage
1 +24V
2
3 +12V
4
5 +8.5V
6
Description
Normal
24 VA
35 VA
Normal
0.36 A
0.27 A
0.70 A
0.50 A
1.00 A
0.70 A
