CHAPTER 4 Settings and Measurement
(4) Basic functions
(1) View and change the settings
Connect to GLT400 to change and view the settings.
When the GLT400 is capturing, you can only view the settings.
The items that can be set differ depending on whether the GLT400 is STAND-ALONE mode or REMOTE
mode.
• STAND-ALONE mode: All settings can be set and viewed.
• REMOTE mode: Network settings only can be set and viewed.
(2) File handling
The files in the internal memory and the SD CARD in the GLT40 can be viewed and downloaded.
* It is available in STAND-ALONE mode only.
(3) Monitor
The digital display and the capturing start and stop of the GLT400 can be controlled.
* It is available in STAND-ALONE mode only.
(4) Save/load settings
Operation settings and network settings can be saved in the GLT400's internal memory or SD CARD.
In addition, you can restore the settings by loading the saved file.
(5) USB driver installation
The USB driver must be installed to connect the GLT400 to the PC with the USB.
* To connect via the USB, you need to install the USB driver before that.
(6) Option
The display language and the decimal-point character can be changed and the GLT400 firmware can be
updated.
(5) Start of software
After installing this software, select "Start Button" → "Graphtec" → "GLT400 Setting App" on the task bar of
the screen to start the software.
When you start the software for the first time, the language selection screen is displayed.
Change to the desired language.
(6) Exit of software
To exit the software, press the "Close" button at the bottom of the main screen.
You can also close it from the [×] button described below.
The setting information entered last when the software is closed is retained. If you exit this application
(When forcibly exited, etc.) other than the above, it is not retained.
4-4
Close
