Specifications

3.1

Feature List

Table 4 Feature Summary
Form Factor
Supported Modules
Back Panel
Connectors
Onboard Connectors
and Features
Optional Onboard
Interfaces
Other Features
Note
1. Available only on ARM-based variant (PN:020750)
2. The module must also support the features for them to function. Refer to the module's user's guide for information about supported
features.
Copyright © 2020 congatec AG
3.5 " form factor (146 mm x 102 mm)— SMARC
ARM-based and x86-based SMARC modules
1 x DC-IN
2 x Gigabit Ethernet RJ45 port
1 x HDMI port
1 x DP++
Extension Sockets:
1 x M.2 key B, type 2280/2242/3042 (PCIe x2/USB/SIM)
-
1 x M.2 key E, type 2230 (PCIe x1/USB)
-
1 x Mini Card full-size or half-size (PCIe x1/USB)
-
SATA Connectors
1 x Standard SATA 3.0/SATADOM
-
1 x SATA power header (5 V and 12 V)
-
1 x Internal audio header (Line-Out, DMIC)
1 x Mini-FIT power connector
1 x LVDS connector
1 x Backlight power connector
1 x CPU fan header
2 x CAN headers
2 x MIPI-CSI2
2x eDP with LVDS overlay (bottom-side)
Boot from external BIOS flash
® specification, revision 2.0
1 x Audio-Out/MIC jack
1 x USB OTG
2 x USB 3.0 host ports
2 x USB 2.0 host ports
1 x Micro-SIM card slot
2 x RS 232/422/485 header (COM 0 and COM 2)
2 x RS 232 header (COM 1 and COM 3)
1 x Front panel header (power button, reset,sleep, LEDs)
1 x Feature connector (batlow, battery charging, GbE SDP,
watchdog)
1 x GPIO header
1 x SPI/eSPI header
1 x SMB/I2C header
1 x Micro-SD slot
1 x CR2032 CMOS/RTC battery
1 x Power button
1 x Power status LED
SMC1m10
