3.2
Mechanical Dimensions
The conga-SMC1 has the following dimensions:
• lenght of 146 ± 0.1 mm
• width of 102 ± 0.1 mm
• height of 25.1 mm (19.3 mm top-side, 1.6 mm PCB and 4.2 mm bottom-side)
3.3
Environmental Specifications
Temperature
Humidity
Note
The above operating temperatures must be strictly adhered to at all times. The maximum operating temperature refers to any measurable
spot on the modules surface.
Humidity specifications are for non-condensing conditions.
Copyright © 2020 congatec AG
Operation: 0°C to 60°C
Operation: 10% to 90%
Storage: -20° to +70°C (commercial temperature)
Storage: 5% to 95%
SMC1m10
14/50
