4

Specifications

4.1

Feature List

Table 2 Feature Summary
Form Factor
Supported Modules
Power
Back Panel I/O
Connectors
Onboard I/O
Connectors
Other Features
Note
The module must also support these features for them to function. Refer to the module's user's guide for information about supported features.
Copyright © 2022 congatec GmbH
Based on COM Express standard pinout Type 10, rev. 3.0
COM Express™ Type 10 mini module form factor (55 x 85 mm)
1x standard 24-pin ATX connector
1x DC power input (4 mm banana connectors)
1x BR2032 CMOS battery
1x DP
2x USB 3.1 ports
4x USB 2.0 host ports
1x Gigabit Ethernet RJ45 port
1x USB Type B (USB device functionality)
1x PCIe x4 slot
2x PCIe x1 slots
1x mini PCIe socket
1x SIM card socket
1x SD card socket (full-size)
2x LVDS connectors
1x LVDS/Backlight power supply header
2x SATA connectors
1x Disk drive 4-pin connector
1x HDA adapter/debug header
4x COM ports
2x COM port headers (module serial ports)
5x Buttons (power, reset, sleep, lid, 5 V standby power discharge)
1x Beeper
4x Debug displays for post code information
4x Ground test points
1x Voltage test point for COM Express module
Onboard Super I/O
Optional discrete TPM
2x Line-Out jacks
1x Line-In jack
1x Microphone jack
1x Headphone jack
1x Optical S/PDIF-Out
1x I C digital IO expansion header
2
1x CPU fan header
1x SBM header
1x I 2 C EEPROM socket
1x SPI flash header
1x LPC header
1x EPI EEPROM Socket
1x Feature connector
2x USB 2.0 host ports
1x DMIC header
CET0m10 15/58
