P-PIN Primary (Top) Side
P60
USB0+
P61
USB0-
P62
USB0_EN_OC#
P63
USB0_VBUS_DET
P64
USB0_OTG_ID
P65
USB1+
P66
USB1-
P67
USB1_EN_OC#
P68
GND
P69
USB2+
P70
USB2-
P71
USB2_EN_OC#
P72
RSVD
2
P73
RSVD
2
P74
USB3_EN_OC#
Key
P75
PCIE_A_RST#
P76
USB4_EN_OC#
P77
PCIE_B_CKREQ#
P78
PCIE_A_CKREQ#
P79
GND
P80
PCIE_C_REFCK+
P81
PCIE_C_REFCK-
P82
GND
P83
PCIE_A_REFCK+
P84
PCIE_A_REFCK-
P85
GND
P86
PCIE_A_RX+
P87
PCIE_A_RX-
P88
GND
Copyright © 2020 congatec AG
S-Pin
Secondary (Bottom) Side
S61
GND
S62
USB3_SSTX+
S63
USB3_SSTX-
S64
GND
S65
USB3_SSRX+
S66
USB3_SSRX-
S67
GND
S68
USB3+
S69
USB3-
S70
GND
S71
USB2_SSTX+
S72
USB2_SSTX-
S73
GND
S74
USB2_SSRX+
S75
USB2_SSRX-
Key
S76
PCIE_B_RST#
S77
PCIE_C_RST#
S78
PCIE_C_RX+
S79
PCIE_C_RX-
S80
GND
S81
PCIE_C_TX+
S82
PCIE_C_TX-
S83
GND
S84
PCIE_B_REFCK+
S85
PCIE_B_REFCK-
S86
GND
S87
PCIE_B_RX+
S88
PCIE_B_RX-
S89
GND
SMC1m10
