P-PIN Primary (Top) Side
P121 I2C_PM_CK
P122 I2C_PM_DAT
P123 BOOT_SEL0#
P124 BOOT_SEL1#
P125 BOOT_SEL2#
P126 RESET_OUT#
P127 RESET_IN#
P128 POWER_BTN#
P129 SER0_TX
P130 SER0_RX
P131 SER0_RTS#
P132 SER0_CTS#
P133 GND
P134 SER1_TX
P135 SER1_RX
P136 SER2_TX
P137 SER2_RX
P138 SER2_RTS#
P139 SER2_CTS#
P140 SER3_TX
P141 SER3_RX
P142 GND
P143 CAN0_TX
P144 CAN0_RX
P145 CAN1_TX
P146 CAN1_RX
P147 VDD_IN
P148 VDD_IN
P149 VDD_IN
P150 VDD_IN
P151 VDD_IN
P152 VDD_IN
P153 VDD_IN
Copyright © 2020 congatec AG
S-Pin Secondary (Bottom) Side
S122 LCD1_BKLT_PWM
S123 GPIO13
S124 GND
S125 LVDS0_0+ / eDP0_TX0+ / DSI0_D0+
S126 LVDS0_0- / eDP0_TX0- / DSI0_D0-
S127 LCD0_BKLT_EN
S128 LVDS0_1+ / eDP0_TX1+ / DSI0_D1+
S129 LVDS0_1- / eDP0_TX1- / DSI0_D1-
S130 GND
S131 LVDS0_2+ / eDP0_TX2+ / DSI0_D2+
S132 LVDS0_2- / eDP0_TX2- / DSI0_D2-
S133 LCD0_VDD_EN
S134 LVDS0_CK+ / eDP0_AUX+ / DSI0_CLK+
S135 LVDS0_CK- / eDP0_AUX- / DSI0_CLK-
S136 GND
S137 LVDS0_3+ / eDP0_TX3+ / DSI0_D3+
S138 LVDS0_3- / eDP0_TX3- / DSI0_D3-
S139 I2C_LCD_CK
S140 I2C_LCD_DAT
S141 LCD0_BKLT_PWM
S142 GPIO12
S143 GND
S144 eDP0_HPD
S145 WDT_TIME_OUT#
S146 PCIE_WAKE#
S147 VDD_RTC
S148 LID#
S149 SLEEP#
S150 VIN_PWR_BAD#
S151 CHARGING#
S152 CHARGER_PRSNT#
S153 CARRIER_STBY#
S154 CARRIER_PWR_ON
