P-PIN Primary (Top) Side
P28 GBE0_CTREF
P29 GBE0_MDI0-
P30 GBE0_MDI0+
P31 SPI0_CS1#
P32 GND
P33 SDIO_WP
P34 SDIO_CMD
P35 SDIO_CD#
P36 SDIO_CK
P37 SDIO_PWR_EN
P38 GND
P39 SDIO_D0
P40 SDIO_D1
P41 SDIO_D2
P42 SDIO_D3
P43 SPI0_CS0#
P44 SPI0_CK
P45 SPI0_DIN
P46 SPI0_DO
P47 GND
P48 SATA_TX+
P49 SATA_TX-
P50 GND
P51 SATA_RX+
P52 SATA_RX-
P53 GND
P54 ESPI_CS0#
P55 ESPI_CS1#
P56 ESPI_CK
P57 ESPI_IO_1
P58 ESPI_IO_0
P59 GND
Copyright © 2020 congatec AG
S-Pin Secondary (Bottom) Side
S29 PCIE_D_TX+
S30 PCIE_D_TX-
S31 GBE1_LINK_ACT#
S32 PCIE_D_RX+
S33 PCIE_D_RX-
S34 GND
S35 USB4+
S36 USB4-
S37 USB3_VBUS_DET 2
S38 AUDIO_MCK
S39 I2S0_LRCK 2, 3
S40 I2S0_SDOUT 2, 3
S41 I2S0_SDIN
2, 3
S42 I2S0_CK
2, 3
S43 ESPI_ALERT0#
S44 ESPI_ALERT1#
S45 MDIO_CLK
1
S46 MDIO_DAT 1
S47 GND
S48 I2C_GP_CK
S49 I2C_GP_DAT
S50 HDA_SYNC / I2S2_LRCK
S51 HDA_SDO / I2S2_SDOUT
S52 HDA_SDI / I2S2_SDIN
S53 HDA_CK / I2S2_CK
S54 SATA_ACT#
S55 USB5_EN_OC#
S56 ESPI_IO_2
S57 ESPI_IO_3
S58 ESPI_RESET#
S59 USB5+
S60 USB5-
