M.2 Key B Socket

The conga-SMC1 provides an M.2 key B, type 2280/3042 socket X10 for connecting a PCIe WLAN card.

Note

Use switch 3 of DIP SW6 to route the UIM signals from mini Card socket to M.2 type B socket.

Connector Type

X10: M.2 card size 2280/3042

4.2.3

The conga-SMC1 provides an M.2 key E, type 2230 socket (X12) for connecting a PCIe WLAN card.

Connector Type

X12: M.2 card size 2230

X10

X12

SMC1m10
