4.5

Display Connectors

The conga-SMC1 provides the following display interfaces:

• dual-mode DisplayPort (DP++)

• native HDMI

• optional eDP

• LVDS/DSI

4.5.1

The conga-SMC1 provides a DP++ port on connector X22 (upper port). You can connect a DP++ to HDMI dongle to the DP++ port if your

module supports it.

Connector Type

X22: Standard DP cable

X22

SMC1m10

27/50
