Specifications

3.1

Feature List

Table 3 Feature Summary
Form Factor
Supported Modules
Operating
Temperature Range
BMC
Internal Connectors
External Connectors
Software
Other Features
Note
The 1 GbE port X77 supports only BMC management (no support for network connectivity)
1.
Copyright © 2022 congatec AG
Extended ATX (305 mm by 330 mm)
congatec COM-HPC size D and size E server modules
®
-40°C to 85°C
ASPEED AST2600 (IPMI 2.0)
1x ATX 12 V standard power connector
1x EPS 12 V
3x PCIe x4
2x PCIe x8
2x PCIe x16
1x M.2 Key M, socket 3 (2230/2242/2260/2280/22110)
1x KR connector for Ethernet Mezzanine cards
2x SATA
1x SATA power
2x Dual USB 2.0 header (USB ports 4-7)
1x eSPI header
1x General Purpose SPI header
2x Module UART
1x Dual USB 3.1 (USB ports 2-3)
1x 10 GbE RJ45
2x USB 3.1 (Port 0 &1)
AMI Megarc SPX BMC firmware
ASPEED Video BIOS
Thermal and voltage monitoring
CMOS Battery
Boot from external BIOS flash
2x BMC UART
2x System fan (BMC)
1x System fan (module)
1x I2C0 header
1x 12C1 header
1x I2C0 I/O expander header
1x Intel ISP adapter header
1x SMB header
1x GPIO header
1x Front panel header
1x Feature header
2x COM-HPC connectors
®
1x DisplayPort (BMC)
1x 1 GbE RJ45 (BMC Management)
