Specifications

2.1

Feature List

Table 4 Feature Summary
Form Factor
Processor
Memory
Chipset
Onboard Storage
Audio
Ethernet
Graphics Options
Peripheral
Interfaces
BIOS
Power Mgmt.
congatec Board
Controller
Security
Note
Some of the features mentioned in the above Feature Summary are optional and require customized articles. Check the part number of your
module and compare it to the options information list on page 11 to determine what options are available on your particular module. For
more information, contact congatec support.
Copyright © 2017 congatec AG
Based on COM Express™ standard pinout Type 10 Rev. 2.1 (mini size 84 mm x 55 mm)
Intel ® Atom ® , Pentium ® and Celeron ® (Codename: Apollo Lake)
conga-MA5: Up to 8 GB non-ECC DDR3L onboard memory interface with data rates up to 1866 MT/s.
Integrated in SoC
eMMC 5.0 interface up to 128 GB
Intel ® High Definition Audio (Intel ® HD Audio)
Onboard Intel Ethernet Controller I211 (Commercial Variants) or I210 (Industrial Variants) connected to SOC PCIe port 4 - connected via one PCI
®
Express ® x1 link by default
Intel HD Graphics Gen9-LP supporting DirectX12, OpenGL 4.3, OpenGL ES 3.0, OpenCL 1.2, full HW acceleration for HEVC (H2.65), H2.64, MVC,
®
VP8, VP9, MPEG2, VC-1, WMV9 and JPEG/MJPEG
1x Single Channel LVDS 18/24 bpp (default) or eDP interface (assembly option)
1x Dedicated DDI with support for:
-
1x Dual-mode DisplayPort 1.2
-
1x HDMI 1.4b
*2
-
1x DVI
*2
2x SATA 6 Gb/s
Up to 4x PCI Express Gen2 x1 links without LAN (requires custom BIOS)
®
6x USB 2.0 and 2x USB 3.0/2.0
SD (MMC not supported)
2x UART (LPC to Dual-UART as assembly option)
AMI Aptio ® UEFI 5.x firmware; 8 MByte serial SPI with congatec Embedded BIOS features (OEM Logo, OEM CMOS Defaults, LCD Control, Display Auto
Detection, Backlight Control, Flash Update)
ACPI 5.0 compliant with battery support. Also supports Suspend to RAM (S3).
Multi Stage Watchdog, non-volatile User Data Storage, Manufacturing and Board Information, Board Statistics, BIOS Setup Data Backup, I²C bus (fast
mode, 400 kHz, multi-master), Power Loss Control
Integrated Intel PTT (TPM 2.0). Infineon SLB9665 (LPC TPM 2.0) or SLB9660 (LPC TPM 1.2) available by assembly option.
®
NOTE:
*1
Either eDP or LVDS signals supported. Both signals are not supported.
*1
Requires an external level shifter on the carrier board.
*2
GPIOs muxed with SD card (not both types simultaneously)
SPI Bus (For external BIOS FLASH only)
LPC Bus
I²C Bus, multimaster
SMBus
