1

Introduction

1.1 SMARC™ Concept
The Standardization Group for Embedded Technologies e.V (SGET) defined the SMARC standard for small form factor computer modules
that target low power, low cost and high performance applications. The SMARC connector and interfaces are optimized for high-speed
communication, and are suitable for ARM SoCs and low power x86 SoCs.
The SMARC standard bridges the gap between the COM Express standard and the Qseven standard by offering most of the interfaces defined
in the COM Express specification at a lower power. With a footprint of 82 mm x 50 mm or 82 mm x 80 mm, the SMARC standard promotes the
design of highly integrated, energy-efficient systems.
Due to its small size and lower power demands, PC appliance designers can design low cost devices as well as explore a huge variety of product
development options—from compact space-saving designs to fully functional systems. This solution allows scalability, product diversification
and faster time to market.
1.2

conga-SMC1

The conga-SMC1 carrier board is designed based on the SMARC 2.1 Specification. With a footprint of 82 mm x 50 mm, the conga-SMC1
provides most of the functional requirements for any SMARC application. These functions include, but are not limited to a rich complement of
contemporary high bandwidth serial interfaces such as PCI Express, Serial ATA, USB 3.0/2.0, and Gigabit Ethernet. .
By combining the scalability of SMARC modules, the conga-SMC1 carrier board provides manufacturers and developers with a platform to
jump-start the development of ARM-based or x86-based SMARC systems. This helps to reduce product design cycle and encourages rapid
innovation in system design, to meet the ever-changing needs of the market.
The conga-SMC1 is an ideal platform for developing ARM-based or x86-based embedded systems because of the various features and
capabilities it offers.
1.2.1

Order Number

Table 1 Order Description
Part Number
020750
020751
Copyright © 2020 congatec AG
Product Name Description
conga-SMC1/SMARC-ARM 3.5 " carrier board for SMARC-based ARM modules
conga-SMC1/SMARC-x86 3.5 " carrier board for SMARC-based x86 modules
SMC1m10 9/50
