Changing the software size

Click one of the three boxes at the bottom of the screen to choose
between the small, medium, and large display sizes.

SSMA communication basics

Figure 30. Communication button, main screen
SSMA can connect to your sensors via a serial (RS-232 or RS-485)
or Internet (IP address) connection; this may require additional
equipment. There is also a virtual option for testing or demo
purposes.

Making a serial connection

Figure 31. For serial connections
Note. Click the
lightning bolt icon to
connect using the
same settings as your
previous connection.
Note. You may need
a USB to serial
adapter to connect
to your computer.
