Setting
Delay (s)
Extend (s)
Alert settings
Enabled
Logic
Zones Inverted
Zone settings
Range (ft)
Description
Sets how long, in
seconds, the sensor
delays the channel
output.
Sets how long, in
seconds, the sensor
extends the channel
output.
Turns the alert on.
If you're using more
than one zone, this
allows you to apply
AND or OR logic to
zone outputs.
Lets you invert the
zone's output.
Lets you enable
a zone and set its
range.
Details
It is recommended
that you change delay
settings in the traffic
controller. If needed,
you can also change
delay settings in the
SSMA software.
It is recommended
that you change
extend settings in
the traffic controller.
If needed, you can
also change extend
settings in the SSMA
software.
One alert is enabled
by default.
OR means the alert
will be triggered if
one or more zones
are activated; AND
means the alert will
be triggered if all
enabled zones are
activated.
If one of these boxes
is checked, the output
will remain on until a
detection in a zone
deactivates it.
Click the Range field
and then drag a zone
onto the roadway
to enable it. Either
click and drag the
blue zone arrows or
change the values in
the Range field to set
zone length.
Chapter 7: Setup Channels-Alerts-Zones 
57
