Advanced Internet Connection Settings
Figure 34. Advanced Internet connection settings
Setting
Timeout
Buffer
Multi-drop Network
If there is only on sensor on the bus, leave this set to Isolated
Sensor. If your connection can see several sensors (they're all
on a single bus, for example), set this to Multi-drop Network and
enter the sensor ID of the sensor you want to connect to. You can
also select Automatically detect sensors and click Connect and a
window will appear with a list of each detected sensor.
Description
How long the
software tries to
connect to the sensor
before it gives up.
The number of bytes
used by the software
to store data received
from the sensor.
Details
Increase this time if
you're having trouble
connecting to the
sensor.
Only change this if
you are connecting
to a complex serial
device. Contact
Wavetronix Technical
Support before
changing this setting.
