Setting
Delay (s)
Extend (s)
Max (s)
Alert settings
On Alert/Off Alert
Enabled
Logic
Zones Inverted
Description
Sets how long, in
seconds, the sensor
delays a channel
output.
Sets how long, in
seconds, the sensor
extends a channel
output.
This is the maximum
amount of time, in
seconds, that the
latched channel will
remain active.
Allows you to set
which zones will
trigger the On and Off
alerts.
On/Off alerts are
always enabled with
Latched channels.
If you're using more
than one zone, this
allows you to apply
AND or OR logic to
zone outputs.
Lets you invert the
zone's output.
Details
It is recommended
that you change delay
settings in the traffic
controller. If needed,
you can also change
delay settings in the
SSMA software.
It is recommended
that you change
extend settings in
the traffic controller.
If needed, you can
also change extend
settings in the SSMA
software.
Click the checkbox
in order to use this
setting.
Click the appropriate
tab to change
settings.
N/A
OR means the alert
will be triggered if
one or more zones
are activated; AND
means the alert will
be triggered if all
enabled zones are
activated.
If one of these boxes
is checked, the output
will remain on until a
detection in a zone
deactivates it.
