Figure 25. Connecting power cable to terminal blocks
Start by connecting the power cable. This backplate is shipped
3
from Wavetronix with the conductors in the cable already ter-
minated in a terminal block plug. Insert this plug into the power
terminal blocks.
If for some reason the conductors aren't terminated into the
4
terminal block plug, terminate them by inserting each conduc-
tor into the corresponding round hole on the plug (match each
conductor to the label of the same color on the plug). Do not
strip the insulation. Insert a small screwdriver into the square
hole above it, and rock upwards to secure the conductor in
place. Repeat with each conductor.
Connect a 12 AWG wire from the earth ground terminal block to
5
the cabinet's earth ground.
