  • Page 1 SmartSensor V USER GUIDE...
  • Page 2 SmartSensor V USER GUIDE www.wavetronix.com • 78 East 1700 South Provo, Utah 84606 • 801.734.7200...
  • Page 3 © 2018 Wavetronix LLC. All Rights Reserved. Wavetronix, SmartSensor, Click, Command, and all associated product names and logos are trademarks of Wavetronix LLC. All other products or brand names as they appear are trademarks or registered trademarks of their respective holders.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction SmartSensor V Package 6 • Selecting a Mounting Location 6 Part I Installing the SmartSensor V Chapter 2 Installing the SmartSensor V Selecting the Offset and Mounting Height 13 • Attaching the Mount Bracket to the Pole 15 • Attaching the Sensor to the Mount Bracket 16 •...
  • Page 5 Chapter 6 Sensor Settings Sensor Info 47 • Sensor Settings 48 • Sensor Date & Time 55 • Operating Mode 56 Chapter 7 Lane Setup Lane Configuration – Automatic 57 • Lane Configuration – Manual 60 • Verifying Lane Configuration 65 Chapter 8 Data Collection Data Collection Setup 71 •...

  • Page 6: Chapter 1 Introduction

    ˽ SmartSensor V Package ˽ Selecting a Mounting Location The Wavetronix SmartSensor V utilizes patented Digital Wave Radar™ technology to detect lane occupancy, traffic volume and average speed in up to eight lanes of traffic simultane- ously. Classified as frequency modulated continuous wave (FMCW) radar, SmartSensor V collects data using a 10.525 GHz (X-band) operating radio frequency.
  • Page 7 INTRODUCTION • SMARTSENSOR V USER GUIDE SmartSensor V Package A typical sensor package contains the following items: ˽ 10.525 GHz SmartSensor V radar traffic sensor ˽ SmartSensor mounting kit ˽ SmartSensor 8-conductor cable ˽ SmartSensor Manager software SmartSensor V User Guide ˽...
  • Page 8 Roadway Figure I.1 – Portable (left) and Permanent (right) Sensor Stations Freeway Locations – The SmartSensor V is often used at permanent ATR stations. The ˽ number of stations along a single roadway and the distance between stations should be selected to achieve adequate levels of statistical confidence.
  • Page 9 highways, are used to establish seasonal adjustment factors for count data from tempo- rary collection sites (see Figure I.1). ˽ Cable Lengths – Make sure that you have sufficient homerun and sensor cabling. Cable runs as long as 600 ft. (182.9 m) using 24 VDC operation and RS-485 communications. For longer connections, alternate wired and wireless options should be considered.

  • Page 12: Part I Installing The Smartsensor

    Part I Installing the SmartSensor V Chapter 1 – Installing the SmartSensor V Chapter 2 – Connecting Power and Surge Protection...

  • Page 14: Installing The Smartsensor V

    ˽ Applying Silicon Dielectric Compound ˽ Connecting the 8-conductor Cable Installing the SmartSensor V is quick and easy. Once installed, the SmartSensor V requires little or no on-site maintenance. This chapter will describe the installation process, includ- ing how to attach the sensor to the pole and how to correctly align the sensor.
  • Page 15 CHAPTER 1 • INSTALLING THE SMARTSENSOR V Figure 1.1 – Mounting and Aiming a SmartSensor V Offset from 1st Recommended Minimum Maximum Detection Lane Mounting Height Mounting Height Mounting Height (ft / m) (ft / m) (ft / m) (ft / m) 9 / 2.7...
  • Page 16 CHAPTER 1 • INSTALLING THE SMARTSENSOR V 33 / 10.1 23 / 7 19 / 5.8 33 / 10.1 34 / 10.4 23 / 7 19 / 5.8 34 / 10.4 35 / 10.7 23 / 7 20 / 6.1 35 / 10.7...
  • Page 17 Use the following steps to securely fasten the sensor to the mount bracket (see Figure 1.3). Align the bolts on the back of the SmartSensor V with the holes in the mounting brack- et. The 10-pin connector on the SmartSensor V should be pointing towards the ground.
  • Page 18 Use the following steps to correctly apply the silicon dielectric compound: Tear the tab off the tube of silicon dielectric compound. Squeeze about 25% of the silicon into the connector at the base of the SmartSensor V. Be sure to wipe off any excess compound.

  • Page 20: Connecting Power And Surge Protection

    Appendix A of this document. Connecting Lightning Surge Protection The first item of concern is surge protection. The SmartSensor V has onboard surge protec- tion, meaning that unlike the SmartSensor HD, the V does not require a pole-mount box;...
  • Page 21 (if this is the case and you need more information, contact Wavetronix Technical Services). In most cases, however, an installation looks like the figure below (though in some cases, rack cards are used).
  • Page 22 Figure 2.2 – Surge Protected Terminal Connections (Top) Follow the diagram above to wire into the UNPROTECTED side of the Click 200. Note The predecessor to the SmartSensor V, the 105, used the 9-conductor cable. For information on this cable, see Appendix B. Grounding The Click 200 device in the main traffic cabinet should be grounded.
  • Page 23 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION The SmartSensor V itself also needs to be grounded via its grounding lug. Connect a grounding wire to the grounding lug on the bottom of the sensor (see Figure 2.3). Figure 2.3 – Grounding Lug on SmartSensor V Connect the other end of the grounding wire to the earth ground for the pole that the sensor is mounted on.
  • Page 24 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION All of the modules discussed in the next few sections will go side by side on a DIN rail in the main traffic cabinet, as shown in Figure 2.4. Earth Ground Black (Ground) Black (Line) Red (+24 VDC) Green (Ground)
  • Page 25 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Wiring AC Surge Protection To include AC surge protection in your installation (see Figure 2.4): Mount the Click 230 onto the DIN rail. Connect the line conductor (hot) from the Click 210 to terminal 5 on the IN side of the Click 230.
  • Page 26 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Note The NC screw terminal is not connected internally. Connecting a wire to a no con- nect (NC) terminal simply gives it a convenient termination point. Wiring DC Power Out of the Click 201/202 Connect a +DC conductor (usually a red wire) to the + screw terminal on the bottom of the Click 201/202 (see Figure 2.6).
  • Page 27 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION Connecting Power through the T-bus The Click 200 is mounted on the T-bus, which consists of a number of small modules that pass power and communications to any device mounted on them. For this reason, one way to get power to a Click 200 is to provide power to the T-bus via the 5-position screw termi- nal.

  • Page 28: Wiring Communication

    The question then becomes what communication options will best suit the installation. Wavetronix Click products facilitate a wide variety of additional wired and wireless com- munication options. Contact a Wavetronix-authorized technical representative to find out which options are best suited for your application.
  • Page 29 CHAPTER 2 • CONNECTING POWER AND SURGE PROTECTION closure cards can be daisy-chained together. However, the chain should not be connected until each card has been independently programmed. Note Wait to connect contact closure communications until after the sensor is pro- grammed using the configuration software.

  • Page 30: Part Ii Using Smartsensor Manager

    Part II Using SmartSensor Manager Chapter 3 – Getting Started with SmartSensor Manager Chapter 4 – Communication Chapter 5 – Sensor Settings Chapter 6 – Lane Setup Chapter 7 – Data Collection Chapter 8 – Tools Chapter 9 – Contact Closure Communications...

  • Page 32: Getting Started With Smartsensor Manager

    Installing SmartSensor Manager Follow these steps to install SSM on a PC: To download the install file, go to the Wavetronix website at www.wavetronix.com. Click the Support link near the top of the page. This will bring up a page with icons from the three different Wavetronix product lines.
  • Page 33 Help > About SmartSensor Manager (see Figure 3.1). Figure 3.1 – About SmartSensor Manager Note The newest version of SSM is always available on the Wavetronix website. Table of Contents This user guide presents the features of SmartSensor Manager in the order that they should be used when setting up and using your sensor.
  • Page 34 CHAPTER 3 • GETTING STARTED WITH SMARTSENSOR MANAGER Figure 3.2 – Table of Contents Page Topic – Lists the available topics according to the setup of the software. ˽ ˽ Availability – Shows whether the information is available. If it is available, this will show a Y.
  • Page 35 CHAPTER 3 • GETTING STARTED WITH SMARTSENSOR MANAGER You can access the Table of Contents page from anywhere in SmartSensor Manager; an ac- tive sensor connection is not needed. This enables you to get help information at any time, especially if information about connecting to a sensor is needed. Release Notes The last entry in the Table of Contents is Release Notes, which, when selected, displays information on the current and previous versions of SSM.

  • Page 36: Chapter 5 Communication

    Communication In this chapter ˽ Serial Connection ˽ Modem Connection ˽ Internet Connection ˽ Firmware Upload ˽ Connection Properties ˽ Address Book ˽ Communication Error When the SmartSensor Manager application is opened, you will be taken to the New Con- nection page, where you will be able to connect using one of three connection options: serial, modem, or Internet.
  • Page 37 CHAPTER 4 • COMMUNICATION Figure 4.1 – New Connection Page Clicking OK opens a connection page unique to each connection option. Each connection page contains three function buttons: Advanced, Cancel, and one that allows you to con- nect or dial. The advanced functions for each connection option are specific for each option. Serial Connection To make a serial connection, click the Serial (COM Port) radio button and then OK.
  • Page 38 CHAPTER 4 • COMMUNICATION Figure 4.3 – Advanced Connection Settings PC Com Port Settings – By default, SSM is set to automatically detect PC com port & ˽ baud rate settings. To manually configure these settings, click the Specify PC com port &...
  • Page 39 CHAPTER 4 • COMMUNICATION Figure 4.4 – Modem Connection The phone book icon to the right of the text field allows you to browse for numbers pre- viously saved in the SmartSensor Manager address book (for more information, see the Address Book section later in this chapter).
  • Page 40 CHAPTER 4 • COMMUNICATION ˽ Local Modem Settings – The initialization string and auto-find command can be en- tered in their respective text fields in the Local Modem Settings section. The Restore Defaults button will return these functions to their default settings. The port number and baud rate will be automatically detected by SmartSensor Manager, so these settings cannot be changed.
  • Page 41 CHAPTER 4 • COMMUNICATION Note When this window is first opened, the connection properties for the Internet connec- tion you used most recently will automatically appear in the text fields. The IP icon next to the text fields allows you to browse through previously saved addresses in the SSM address book, which is especially useful if you are connecting to more than one sensor using an Internet connection.
  • Page 42 CHAPTER 4 • COMMUNICATION not part of a multi-drop environment. If the sensor is part of a multi-drop network, SmartSensor Manager can either auto-detect the multi-drop ID, or you can enter the four-digit ID. Clicking the Use Multidrop Protocol… Connect Directly to ID: radio button will activate the text box so you can enter the ID number.
  • Page 43 CHAPTER 4 • COMMUNICATION Exit SmartSensor Manager If you are unsure what to do, you should click the Exit SmartSensor Manager button. When you have decided what to do, you can reconnect to the sensor. In some cases, you may have simply connected to the sensor with the wrong version of SmartSensor Manager.
  • Page 44 CHAPTER 4 • COMMUNICATION ˽ Day.Application – Shows the day of the version’s release in DD format as well as the current application; this will appear as an S for sensor or a D for diagnostic. Connection Properties Information about the current connection can be accessed on the Current Connection Properties page, which is found under File>Properties (see Figure 4.10).
  • Page 45 CHAPTER 4 • COMMUNICATION Accessing the Address Book The address book can be accessed in two ways: Go to File > Address Book. This will give you two options: New and Open. Selecting New will open a directory box where you can create a new address book file (.abf). Creating an address book file will not immediately open the new file.
  • Page 46 CHAPTER 4 • COMMUNICATION Figure 4.12 – Address Book for Modem Entries Use the buttons in the address book to work with entries and make connections: ˽ Select – Selects an entry to use to connect. When you have chosen the entry you would like to use to connect, highlight it in the list and click Select.
  • Page 47 CHAPTER 4 • COMMUNICATION municate with the sensor. If such an error occurs, the Communication Error screen will give you the following options (see Figure 4.13): Retry – Tells SSM to try to communicate with the sensor again. ˽ Cancel – Stops the current operation as well as other operations that may be in process. ˽...

  • Page 48: Sensor Settings

    Sensor Settings In this chapter ˽ Sensor Info ˽ Sensor Settings ˽ Sensor Date & Time ˽ Operating Mode There are several ways to access and change sensor settings using SSM. Sensor Info Going to File>Sensor Info opens the Sensor Information page, which displays the proper- ties unique to each sensor (see Figure 5.1).
  • Page 49 CHAPTER 5 • SENSOR SETTINGS Sensor Information page. The page is divided into two sections, Identification and Firm- ware Versions. The Identification section information includes the following: Serial Number – Shows the 16-digit serial number given to the sensor by the manufac- ˽...
  • Page 50 CHAPTER 5 • SENSOR SETTINGS Figure 5.2 – General Tab Serial Number – Shows the 16-digit serial number given to the sensor by the manufac- ˽ turer, used to uniquely identify the sensor. This is the only setting on this screen that cannot be edited.
  • Page 51 CHAPTER 5 • SENSOR SETTINGS stalled in close proximity to each other to prevent the sensors from interfering with each other. Communication Tab The Communication tab allow you to change the following settings (see Figure 5.3): Figure 5.3 – Communications Tab Baud Rates –...
  • Page 52 CHAPTER 5 • SENSOR SETTINGS protocol can cause communication messages to be broadcast unintentionally. These messages can result in collisions and even ongoing chatter between sensors on a multi- drop network. If you are setting up a multi-drop network of sensors, you should con- nect to them one by one and disable Simple protocol.
  • Page 53 The following table provides some generic guidance on scale factor values. In general, lanes further away should have a lower scale factor. Also, a SmartSensor V will tend to have lower scale factors then a SmartSensor 105 at the same location. Below are some...
  • Page 54 CHAPTER 5 • SENSOR SETTINGS Feet SmartSensor 105 SmartSensor V 1.10 1.08 1.07 1.04 1.04 1.00 1.01 0.96 0.98 0.92 0.96 0.89 0.94 0.86 0.91 0.83 0.89 0.81 0.87 0.78 0.85 0.76 0.83 0.74 0.81 0.72 0.80 0.70 0.78 0.68 0.77...
  • Page 55 CHAPTER 5 • SENSOR SETTINGS Note Interval occupancy is derived from event duration, so the occupancy scale factor scales both the duration and the occupancy. Additionally, the length-based event classifica- tion is derived from the event duration and the event speed, so scaling either the speed or the duration will impact the classification results.
  • Page 56 CHAPTER 5 • SENSOR SETTINGS Note Using the Save to File function does not save the changes to your sensor. If you want to update and then back up your sensor, you need to use both Save to File and Save to Sensor.

  • Page 57: Operating Mode

    SmartSensor Advance, which can detect vehicles in multiple lanes up to 500 ft. (152.4 m) in advance. If you would like to use the SmartSensor V in Forward Fire mode, call Wavetronix Techni- cal Services at 801-764-0277 for assistance and further instruction.

  • Page 58: Lane Setup

    Lane Setup In this chapter ˽ Lane Configuration – Automatic ˽ Lane Configuration – Manual ˽ Verifying Lane Configuration Setting up lanes is simple in SmartSensor Manager because the software will do it for you with the click of a button. Additionally, if SmartSensor Manager is unable to correctly con- figure due to barriers, obstacles or irregular lanes, you can use the Manual Configuration mode to adjust.
  • Page 59 CHAPTER 6 • LANE SETUP Click the Restart button at the lower right. Confirm the configuration restart by clicking Yes in the box that appears (see Figure 6.1). SmartSensor Manager will now automatically begin detecting and configuring lanes, and the screen will show a visual depiction of the lanes and vehicle detections in real time.
  • Page 60 CHAPTER 6 • LANE SETUP Click the Restart button to apply the range blinders. When the range blinders are ap- plied, they will turn from a red color to a dark khaki color. To cancel and use the default ranges, or to start over, or click the Range Blinders button again. After the lanes are detected and configured correctly, save the configuration by click- ing the Finished button.
  • Page 61 CHAPTER 6 • LANE SETUP Note The default starting point of 5 is also the largest starting point allowed. If you enter a value larger than 5 the default starting point of 5 will be used. If you are managing the gain, you should generally change the starting point to a 3 or 4.
  • Page 62 CHAPTER 6 • LANE SETUP Lane Center Lane Divider Shoulder Figure 6.3 – Adjusting Lanes Paint and Remove Lines The Paint Lines button allows you to add new lanes by inserting lane dividers in paved (black) areas. SmartSensor Manager allows a maximum of eight lanes. Again, the cursor will change from an arrow to a hand when it is positioned directly over a location where it is possible to paint a lane divider.
  • Page 63 CHAPTER 6 • LANE SETUP Construct and Remove Barriers Constructing a barrier or median is essentially the act of dividing a single road into two separate roads. SmartSensor Manager defines a barrier or median as two adjacent shoulder lines or two shoulder lines with only background (khaki-colored) areas in between them. To construct a barrier or median, click on the Construct Barriers button and move the cur- sor to the paved area where you want to insert the barrier.
  • Page 64 CHAPTER 6 • LANE SETUP Edit Lane Names By default, the SmartSensor V identifies the lanes it configures as lane 1 up to lane 8, where lane 1 is located closest to the sensor. However, you may wish to assign lane numbers differ- ently with the Edit Lane Names window (see Figure 6.5).
  • Page 65 Lane Configuration page by clicking on the Finished button located at the bottom right of the screen. A window will appear indicating that the changes are being saved to the SmartSensor V. After the changes have been saved, SmartSensor Manager will automatically change from Lane Configuration to Traffic (Event) Data View mode so that you can verify lane configu- ration.
  • Page 66 Traffic (Event) Data In Event mode, this screen allows you to verify the SmartSensor V’s configuration by com- paring the traffic on the road to event information shown in the window (see Figure 6.8). In order to keep a record of your verification results, the event data can also be saved to a log file while you remain on this screen.
  • Page 67 CHAPTER 6 • LANE SETUP Note A status bar below the Traffic View window indicates whether you are in Event mode or Actuation mode. By default, Traffic View launches in Event mode. In Event mode, the vehicles (represented by the blue rectangles) appear after having passed through the radar detection zone. The four icons located at the bottom of the screen are active in this mode.
  • Page 68 CHAPTER 6 • LANE SETUP Figure 6.10 – Event Log The event log file breaks down each event and reports back the event Timestamp, Lane Name, Duration, Event Speed, Class, and Count. The timestamp, which is formatted using the local time zone settings on your computer in hours, minutes, seconds and milliseconds, is the time the vehicle entered the detection zone.
  • Page 69 CHAPTER 6 • LANE SETUP Figure 6.11 – View Interval Data Before interval data verification is performed, do the following: Specify the desired interval length in the Interval (Bin) Size edit box. To do this, enable the edit box by clicking Edit, then type the desired length of the interval in seconds and click Submit.
  • Page 70 CHAPTER 6 • LANE SETUP ˽ Lane Name – Displays the string of eight alphanumeric characters that describes the lane. ˽ Volume – Shows the number of events during the interval. ˽ Interval Lane Speed – Represents the average speed of the lane during the time of the interval.

  • Page 72: Data Collection

    Data Collection In this chapter ˽ Data Collection Setup ˽ Data Download ˽ Data Logs Once you’ve set up your sensor and lanes, you can collect data for studies. This chapter outlines the steps necessary for data collection Data Collection Setup Go to Data Collection >...
  • Page 73 CHAPTER 7 • DATA COLLECTION Step 1: Configure Data Storage The Interval (Bin) Size option specifies the interval of time over which traffic variables like volume, speed, occupancy and classification are aggregated. This type of data is called inter- val data. The minimum interval allowed is five seconds. By default, the checkbox next to Memory Overwrite is checked.
  • Page 74 CHAPTER 7 • DATA COLLECTION Interval Data Buffer Status As soon as the study begins, the View Interval Data Buffer Status window will appear. This window shows you how much of the guaranteed onboard storage space is filled with inter- val data.
  • Page 75 CHAPTER 7 • DATA COLLECTION Data Download To download interval data stored on the sensor in the SRAM and flash memory buffers— such as data collected in a study—go to Data Collection > Download. The screen that comes up is divided into two sections, Download Interval Data and Interval Data Buffers (see Figure 7.3).
  • Page 76 CHAPTER 7 • DATA COLLECTION Note Each time a data download is performed, a header is inserted into the log file that indi- cates the date of the download. Data in the SRAM buffer contains the most recent information and will be downloaded first.
  • Page 77 CHAPTER 7 • DATA COLLECTION Note If you are not sure when your storage space will completely fill up with data; you can click on the View Data Buffer Status button and monitor its progress. You can also look at the Flash Storage Time entry on the Data Collection Setup screen to see how long you have before the flash memory fills up.
  • Page 78 CHAPTER 7 • DATA COLLECTION Note You can also open event and interval logs by going to View > Traffic (Event) Data or View > Interval Data and clicking the View Log button; you can view download logs by selecting the View data file when this window is closed button after downloading. Export Select File >...
  • Page 79 CHAPTER 7 • DATA COLLECTION can tell which lane you’re working with, the lanes are numbered under the Sensor Log File heading, with the lane closest to the sensor at the top of the list. While multiple lanes may have the same direction, no two lanes may have both the same direction and number, unless that number is 0.

  • Page 80: Tools

    The message response will be returned in the gray scrollable area below the Command Line. You may also use binary mode to verify operation of binary protocols supported by the SmartSensor V by clicking the Binary Mode button.
  • Page 81 CHAPTER 8 • TOOLS Figure 8.1 – Hyperterminal Firmware Upload When you first connect, the program will prompt you to update your firmware if it sees a discrepancy between the software and firmware versions, but you can also go at any time to Tools >...

  • Page 82: Contact Closure Communications

    ˽ Programming Sensors for Contact Closures ˽ Programming Contact Closures In many applications, you will not need to use your SmartSensor V with contact closure cards. Often traffic data is collected directly from the sensor via a serial, modem or Internet connection.
  • Page 83 The Click 100 supports baud rates from 9600 to 57600 bps. When using a Click 100, make sure your SmartSensor V is set to operate at a baud rate in this range. The Click 500 modules support baud rates from 9600 to 115200 bps. Any special program- ming of SmartSensor for an application running on the Click 500 will be explained in the documentation for that application.
