SmartSensor Advance User Guide
48
•
Setting Description
Traffic Shows the direction
of traffic the sensor is
currently detecting.
Stopbar Represents the location
of the stopbar on the
roadway. To move it, drag
the stopbar up and down
the roadway or use the
Stopbar arrows.
The stop bar will always
have a distance of 0.
Sensor Represents the location
of the sensor on the
roadway. To move it, drag
the stopbar up and down
the roadway or use the
Sensor arrows.
The top number
represents how many
feet the sensor is to the
left or right of the center
of the lanes of interest.
The bottom number
represents how many feet
the sensor is in front of or
behind the stop bar.
Height Lets you enter the
sensor's height.
Details
Click the button to change
the arrow direction.
The stopbar and sensor
location may affect
channel configuration.
The stopbar and sensor
location may affect
channel configuration.
The sensor height may
affect range accuracy.
