Mounting location, height and offset
Figure 2. The SmartSensor Advance and Advance Extended Range
The SmartSensor Advance and SmartSensor Advance Extended
˿
Range detect moving traffic out to a maximum range of 600 ft.
(182.9 m) and 900 ft. (274.3 m) respectively. Place the sensor at
least 50 ft. upstream from the edge of the first detection zone.
Choosing a Mounting
600 ft
900 ft
footprint
1
Location
Chapter 1: Choosing a Mounting Location
9
•
