SmartSensor Advance User Guide
66
•
primarily used to distinguish between the dilemma zones of larger
vehicles, such as trucks and buses, and the dilemma zones of
smaller vehicles.
Setting up a Priority channel
Click a channel tab and then click the Enabled checkbox.
1
Enter a channel name.
2
Select Priority from the Type drop-down menu.
3
Change the zone settings and click OK.
4
Setting
Channel settings
Name
Type
Enabled
Level 1, Level 2 settings
Discovery Range
(feet)
Range (feet)
Description
Lets you set a name
for the channel.
Lets you select the
channel type.
Turns the channel on.
Sets the discovery
range threshold,
which allows you to
differentiate between
high-priority vehicles
(trucks, busses) and
smaller vehicles.
Lets you enable
a zone and set its
range.
Details
This setting is
optional.
Select Priority here.
This checkbox must
be checked for
normal operation.
Use the up/down
arrows to change
the Discovery Range
threshold. Adjust
this so that most
large vehicles are
discovered beyond
the threshold
(Level 1) and most
smaller vehicles are
discovered after it
(Level 2).
Either click and drag
the blue zone arrows
anywhere along the
roadway or change
the values in the
Range field.
