Setting
Buffer
Flow Control
Parity
Stop Bits
Data Bits
Description
The number of bytes
used by the software
to store data received
from the sensor.
Allows you to use flow
control handshaking
to keep up with the
data rates of higher-
performance devices.
In serial protocol,
this is a bit added to
a string of code so
that the total number
of bits in the string is
even or odd.
In serial protocol,
this indicates that the
transmission of a byte
has ended.
In serial protocol, this
is the number of bits
used to represent one
character of data.
Details
Only change this if
you are connecting
to a complex serial
device. Contact
Wavetronix Technical
Support before
changing this setting.
This should be set to
None. Change this to
Hardware if you're
connecting through
a device that uses
RS-232 hardware
handshaking.
This should always be
set to None. Contact
Wavetronix Technical
Support before
changing this setting.
This should always
be set to 1. Contact
Wavetronix Technical
Support before
changing this setting.
This should always
be set to 8. Contact
Wavetronix Technical
Support before
changing this setting.
