Wavetronix SmartSensor Advance User Manual page 75

Tip. Click and hold
on the Roadway
button to view all
the display options.
SmartSensor Advance User Guide
74
•
Click the left sidebar button until the scale appears. This shows
1
a distance scale relative to the stop bar.
Using the scale you can do a quick visual check of detection
2
accuracy.
Changing the roadway display
Many types of data can be displayed inside the tracker on the
roadway. The roadway display button is used to cycle through the
different tracker display options.
Setting
Range (ft)
Speed (mph)
ETA (s)
ID
Qualified Count
Description
Shows the distance
from the vehicle to
the stop bar.
Shows the vehicle's
speed.
Shows the vehicle's
estimated time of
arrival (in seconds) to
the stop bar.
Shows the tracker
ID number. SSMA
assigns a unique five-
digit identification
number to each
tracker.
Shows Qualified
Count and Dynamic
Density data.
Details
N/A
N/A
N/A
N/A
The data displayed on
the trackers depends
on the channel type
selected in the Setup
Channels-Alerts-
Zones screen.
