Setting up a Simple channel

Click a channel tab and then click the Enabled checkbox.
1
Enter a channel name.
2
Select Simple from the Type drop-down menu.
3
Change the desired settings and click OK.
4
Setting
Channel settings
Name
Type
Enabled
Zone settings
Range (feet)
Speed (mph)
ETA (seconds)
Description
Lets you set a name
for the channel.
Lets you select the
channel type.
Turns the channel on.
Lets you enable
a zone and set its
range.
Lets you set the
speed thresholds that
will trigger the zone
output.
Lets you set the
ETA thresholds that
will trigger the zone
output.
Details
This setting is
optional.
Select Simple here.
This checkbox must
be checked for
normal operation.
Either click and drag
the blue zone arrows
anywhere along the
roadway or change
the values in the
Range field.
Click inside the
Speed field and use
the up/down arrows
to change the speed
filter. The channel
will only be triggered
if a vehicle's speed
is within the speed
thresholds.
Click inside the ETA
field and use the
up/down arrows to
change the ETA filter.
The channel will
only be triggered if a
vehicle's ETA to the
stop bar is within the
ETA thresholds.
Chapter 7: Setup Channels-Alerts-Zones
Note. The speed
and ETA filters will
only be activated if
the Speed and ETA
boxes are checked.
