Note. The speed
and ETA filters will
only be activated if
the Speed and ETA
boxes are checked.
SmartSensor Advance User Guide
62
•
Setting
Zone settings
Range (ft)
Speed (mph)
ETA (s)
Qualified Count
Dynamic Density
Description
Lets you enable
a zone and set its
range.
Lets you set the
speed thresholds that
will trigger the zone
output.
Lets you set the
ETA thresholds that
will trigger the zone
output.
Lets you limit a zone's
output to times when
there are a certain
number of detections
in a zone at one time.
Lets you limit a zone's
output to times
when the number of
detections in a zone
equal or exceed a
density requirement.
Details
Click the Range field
and then drag a zone
onto the roadway
to enable it. Either
click and drag the
blue zone arrows or
change the values in
the Range field to set
zone length.
Click inside the
Speed field and use
the up/down arrows
to change the speed
filter.
The zone ouput will
only be triggered if
a vehicle's speed
is within the speed
thresholds.
Click inside the ETA
field and use the
up/down arrows to
change the ETA filter.
The zone ouput will
only be triggered if a
vehicle's ETA to the
stop bar is within the
ETA thresholds.
The channel will only
be triggered if the
number of vehicle's
in a zone are within
the Qualifed Count
thresholds.
The channel will
only be triggered
if a vehicle meets
the Headway, %
Utilization and Tuning
Factor requirements.
