Note. Trigger speeds
show the speed of
the detected vehicles
that activated the
channel and are
normally used with
Pulse channels.
SmartSensor Advance User Guide
82
•
Setting
Specify output
minimum duration
Specify output
frequency
Select trigger speed options
Port
Channel
Tag
Description
Allows you to specify
the minimum amount
of time a channel
output will be on (in
seconds).
Allows you to set
the minimum time
between channel
outputs.
Indicates which port
the trigger speeds will
be pushed on.
None = disabled
Port 1 = control bus
Port 2 = data bus
Monitors alert 1 and
zone 1 of the selected
channel.
Allows you to define
a 6-character tag
that will help identify
which intersection
the speed came from.
This tag is inserted
after the speed bytes
of the trigger speed
message.
Details
May be useful for
detections that
occur very quickly
and need to be
held long enough
for the system to
recognize and use
the information.
In most cases, the
default value of 0.13
seconds will work
fine.
In most cases, the
default value of 0.13
seconds will work
fine.
Select port 1 or 2 to
push speeds and
select None if you
don't want to push
trigger speed data.
Select the pulse
channel you want to
use to gather trigger
speed data.
Enter a unique
6-character tag to
identify intersection
location.
