Prepare the sensor while still on the ground: remove the large
1
bolts holding the end knuckle to the mount, then use the
four small bolts and lock washers to attach the knuckle to the
sensor backplate.
Once you're ready to mount the sensor on the pole, insert the
2
mounting straps through the slots on the mount.
Position the mount on the pole in the spot you chose from the
3
previous chapter.
Tighten the straps.
4
Attach the knuckle you prepared earlier to the mount using the
5
large bolts (the cable connector should be pointed down). Don't
tighten completely yet, as you still need to align the sensor to
the roadway.

Sensor alignment

Aligning the sensor to the roadway

Determine the distance to the target. The target is the exact
1
spot on the road that the sensor should be pointing at. Find the
target distance by using the sensor's height and offset in the
following table(s).
17
0 40
5
45
10
50
15
50
20
55
25
60
30
65
35
70
40
80
45
95
50
100
Height
20 25
45 55
45 60
50 60
55 65
55 65
65 65
70 75
75 85
90 90
100 100
100 105
Table 1. Target distance in feet
30 35 40
60 70 75
65 70 80
65 75 80
70 75 80
75 80 90
75 80 90
80 85 95
85 95 95
95 95 100
100 100 105
110 115 120
Chapter 2: Installing the SmartSensor Advance
Note. Be sure to
keep the straps
adjustable, because
once you've used the
alignment tool in the
software, you may
need to fine-tune the
sensor's positioning.
Note. In some
cases, it is possible
to increase
performance at far
ranges by increasing
the target distance
by 25-50 ft.
