Setting
Zone settings
Range (feet)
Speed (mph)
Priority channel
Figure 64. Priority channel, level 1 and level 2 zones
A Priority channel has three zones. The channel output is triggered
when any one of the three zones is triggered. A Priority channel is
Description
Lets you enable
a zone and set its
range.
Lets you set the
speed thresholds that
will trigger the zone
output.
Details
Either click and drag
the blue zone arrows
anywhere along the
roadway or change
the values in the
Range field.
Click inside the
Speed field and use
the up/down arrows
to change the speed
filter.
The zone output will
only be triggered if
a vehicle's speed
is within the speed
thresholds.
Chapter 7: Setup Channels-Alerts-Zones
Note. The speed filter
will only be activated
if the Speed box
is checked.
Note. Priority
channels are
only available
with SmartSensor
Advance Extended
Range.
