SmartSensor Advance User Guide
78
•
Setting
Channel LED turns
red
Alert LED turns red
Zone LED turns a
color
Letter next to
channel LED
Letter under channel
LED
Description
The channel output is
triggered.
The alert output is
triggered.
A zone output is
triggered.
Shows the channel
type.
Shows the channel
settings.
Details
A channel output
is triggered when
the associated
alert outputs fulfill
the channel's
requirements.
An alert output is
triggered when the
associated zone
outputs fulfill the
alert's requirements.
A zone output is
triggered when its
detection filters are
met.
Each zone is
represented by a
different color.
Zone 1 = green
Zone 2 = blue
Zone 3 = yellow
Zone 4 = red
S = Simple
N = Normal
L = Latched
P = Priority
Pu = Pulse
D = Delay
E = Extend
M = Max timer
