External Router - MB Connect Line mbNET MDH810 Manual

10.1.1

External Router

If you selected External Router, you will be redirected to the WAN-Settings.
Label
WAN Typ
DHCP:
The router obtains his connection information like the IP address and the
subnetmask via DHCP (Dynamic Host Control Protocol).
The router will obtain connection information such as IP address and
subnet mask using DHCP. Gateway and DNS servers can be specified as
an option.
Static IP:
Set the connection information manually. There will appear the following
two input fields, enter your required data here.
IP address:
Specify an IP address.
Netmask:
Specify the netmask for the IP address
Gateway
Enter the IP address of the Gateway.
DNS Server Enter the IP address of the DNS Server.
Use Proxy Check the checkbox if you need to use a proxy.
Click "Next"
Description
Page 27 of 226
Version: 3.3.5 – DR05 – 23.03.2017
