MB Connect Line mbNET MDH810 Manual page 174

Tab
Connection Set-
tings
A "network to network" connection can be created here. Depending on the authentication method, the client re-
ceives an IP address from a defined range or each subscriber specifies its requested address.
Example:
LAN
[192.168.99.100]<>ROUTING<>[10.1.0.2] VPN – TUNNEL [10.1.0.1]<>ROUTING<>[192.168.0.100]
If „Wait for incoming Connection" was selected, then this mbNET is in Server Mode and is called "Server" in
the further documentation, otherwise if "Connect immediately" was selected, then the mbNET is in Client
Mode and is called "Client".
Page 174 of 226
Version: 3.3.5 – DR05 – 23.03.2017
Label
Active
Connection name
Connection type
mbNET Client
Description
Check this box to activate the OpenVPN con-
nection.
Enter a name for the connection in the input
field.
Select the connection type via the drop-down
field.
mbNET Server LAN
