General data
Voltage V (DC)
Power consumption
IP protection class
Area of application
Operating temperature
Storage temperature
Humidity
Dimensions (max.)
Weight (max.)
Mounting
I/Os and standard interfaces
Digital inputs
Digital outputs
LAN interfaces
USB interface
VPN
VPN protocol
Encryption method
VPN protocol
Encryption method
Encryption algorithm
Authorization
Network / Security
Firewall
IP-Router
Services
Time synchronization
10 – 30V DC (external Power Supply or other SELV Power Supply Source,
rated 10-30V DC, max. 40A)
max. 1300 mA @ 24 V
IP 20
Dry environments
0 – 50 °C
-20 – 60 °C
0 – 95% (non condensing)
48 mm x 137 mm x 140 mm (W x D x H)
650 g
DIN rail mounting (based on DIN EN 50022)
4 pcs. digital inputs (10-30V) (fuse-protected), (Low 0-3,2 V DC, High 8-30 V
DC)
2 pcs. digital outputs (200mA max. / output), 200 mA @ 12 V DC / 100 mA @ 24
V DC
4 pcs. 10/100 Mbit/s full and half duplex operation, autodetection patch cable /
crossover cable
USB Host 2.0
IPsec/PPTP/OpenVPN, 64 tun-
nel
Blowfish, AES, DES/3DES
OpenVPN, 1 tunnel
Blowfish
MD5, SHA1
Pre-Shared-Key, X.509
*
can only be operated with mbCONNECT24, mymbCONNECT24.hosted, -.virtual, -.mini, -.midi or -.maxi
1:1 NAT, IP-Filter, Port forwarding, stateful inspektion
NAT-IP, TCP/IP routing, IP forwarding
DHCP server, DHCP client, DNS server, NTP client, PPP server, DynDNS
NTP server
Item no.: 8812-UL, 8813-UL, 8814-UL, 8830-
UL, 8831-UL, 8833-UL, 8834-UL, 8850-UL-
EU,
8850-UL-AT&T, 8855-UL-EU, 8855-UL-AT&T
Item no.: 8810-UL, 8811-UL, 8815-UL, 8816-
UL, 8817-UL, 8818-UL, 8819-UL, 8835-UL*,
8841-UL, 8849-UL, 8858-UL-EU, 8858-UL-
AT&T, 8859-UL- EU,
8859-UL- AT&T
