20.3
Tag status
Shows the status of the monitored tags.
Label
Number
Description
Address
Value
Timestamp
Valid value
20.4
Diagnostic
You can restart the I/O-Manager here. You can also analyze the logging and the data logger of the I/O-
Manager here.
Number of the tag.
Description of the tag
Address of the tag
Value of the tag, in the data format which was set at the tag.
Shows the exact time when the tag was readed.
Shows if the tag is valid / reachable or not.
Description
Version: 3.3.5 – DR05 – 23.03.2017
Page 193 of 226
