Authentication with certificates
19.3.2.1.2
Tag
Client IP address pool
Network
Settings
Client NAT behind the
local network (The client
will send the IP of the
gateway for traffic
through the local net-
work)
No network settings need to be made on the client side. The server automatically passes
all the information to the client in this mode.
19.3.2.2

Configuring an OpenVPN Windows client

To be able to use the OpenVPN Windows client, it must first be installed on the computer. The installation
routine can be downloaded from
http://openvpn.net/index.php/open-source/downloads.html
The corresponding client setting can be downloaded from the mbNET via the "Download" link (see arrow).
Save this file in the „config" folder of OpenVPN.
With manual configuration of the VPN client, the setting "Local IP address" and "Peer IP
address" must be reversed accordingly on the client.
Page 170 of 226
Version: 3.3.5 – DR05 – 23.03.2017
Label
With authentication with certificates, multiple clients can di-
al into the server simultaneously and are automatically as-
signed an IP address from the "Client IP address pool". En-
ter the address range in CIDR notation. E.g. 10.1.0.0/24
(corresponds to the subnet mask: 255.255.255.0).
The option "Client NAT behind the local network (The cli-
ent will send the IP of the gateway for traffic through the
local network)" assigns all packets coming into the LAN
the sender IP address of the mbNET. Although this means
that it is then no longer possible to distinguish between
senders in the LAN, the LAN subscribers do NOT have to
have the mbNET entered as a gateway.
NOTE - this can become confusing with multiple clients.
Description
.
