Summary of Contents for MB Connect Line mbNET MDH 810

  • Page 1 Technical Data MDH800 - MDH859 (from HW 02) - V 6.0 - DE...
  • Page 2: Technical Data

    Technical data mbNET ® Industrial router MDH 810, MDH 811, MDH 814, MDH 815, MDH 816, MDH 819, MDH 830, MDH 831, MDH 834, MDH 835, MDH 841, MDH 849, MDH 850 EU, MDH 850 AT&T, MDH 855 EU, MDH 855 AT&T, MDH 858 EU, MDH 858 AT&T, MDH 859 EU, MDH 859 AT&T - from hardware version: HW 02 You can find the hardware version on the device rating plate.
  • Page 3 General Data Performance data Voltage V (DC) 10 – 30 V DC (ext. power supply or SELV power supply, 10-30 V DC, Max. 40A) Current consumption max. 1300 mA @ 24 V Random access mem- Devices with hardware version HW03: 512 MB Devices with hardware version HW02: 256 MB IP Protection class IP 30*...
  • Page 4 Network/security Firewall 1:1 NAT, IP-Filter, port forwarding, stateful inspection IP router NAT-IP, TCP/IP routing, IP forwarding Services DHCP server, DHCP client, DNS server, NTP client, PPP server, DynDNS Time levelling NTP server Optional Interfaces WAN interfaces 10/100MBit/s full and half duplex operation, automatic detection patch ca- ble/cross-over cable (auto detection) Interface 1 (COM1) RS-232/485 (software-switchable)
  • Page 5: Simplified Eu Declaration Of Conformity

    SIMPLIFIED EU DECLARATION OF CONFORMITY MB connect line GmbH hereby declares that the radio system type MDH 811, MDH 814, MDH 819, MDH 831, MDH 841, MDH 834, MDH 849, MDH 850 EU, MDH 855 EU, MDH 858 EU, MDH 859 EU corresponds to the 2014/53/EU directive.
  • Page 6: Router Installation

    Router Installation Installation position/minimum clearances The router is designed to be mounted on DIN top hat rails (in accordance with DIN EN 50 022) and for installation in a control cabinet. The installation and assembly must be carried out according to VDE 0100/IEC 364.
  • Page 7 MB connect line GmbH offers universal solutions for worldwide remote maintenance of machines and equipment. The specialists at MB connect line can draw on years of experience and extensive know-how. MB connect line GmbH Fernwartungssysteme Winnettener Str. 6 91550 Dinkelsbühl...
