Server – no authentication or static key
19.3.2.1
Tab
Network Settings
With authentication without certificates, only one IP channel (local IP address and peer IP ad-
dress) can be specified per connection entry.
With manual configuration of the VPN client, the setting "Local IP address" and "Peer IP
address" must be reversed accordingly on the client.
Label
Local IP address
Peer IP address
Local network
Peer network
Description
Enter the IP address of the local VPN tunnel end
point here, e.g. 10.1.0.1
Enter the IP address of the peer VPN tunnel end
point here, e.g. 10.1.0.1
Enter your network address in CIDR notation here
(192.168.0.0/24).
Enter the network address of your peer in CIDR no-
tation here (192.168.99.0/24).
