Quick start-up guide
In the first step, connect the mbSECBOX to a 10-30V DC
voltage power supply.
Connect any LAN Port 1 thru 4 of the mbSECBOX to the network
interface (ethernet interface) of your computer and an other LAN
Port to your PLC.
or connect the mbSECBOX via the MPI/PROFIBUS port to your
PLC.
For the initial configuration must the configuration PC and the
mbSECBOX must be in the same address range as the PLC.
• Default settings mbSECBOX
IP-Address
Subnet mask 255.255.255.0
Login
Password
• Open the internet protocol (TCP/IP) properties by clicking the
local area connection properties button, which allows you to
change your IP address and subnet mask.
• Your computer's IP address needs to be in the address range
PLC-Backup
of "192.168.0.X", the subnet mask needs to be the same as the
& Virus Detection
mbSECBOX's (255.255.255.0)
Enter the IP address of the mbSECBOX (192.168.0.253) as the
default gateway and DNS server address.
Start your browser and enter the required IP address
(192.168.0.253) of the mbSECBOX.
192.168.0.253/
For the mbSECBOX login parameters enter the following:
Username: mbsecbox
192.168.0.253
mbsecbox
mbsecbox
192 . 168 . 0 . X
192 . 168 . 0 . X
255. 255. 255 . 0
255. 255. 255 . 0
192 . 168 . 0 . 253
192 . 168 . 0 . 253
Password: mbsecbox
ADVICE!
Change unconditionally and without delay the
default login information!
IMPORTANT:
If the IP address of the mbSECBOX is changed, you will also
need to change the IP address range of your computer.
After all the changes are saved, you'll have to confirm a device
reboot in order to get the changes to take effect.
For more information on mbSECBOX you can view our handbook
by going to our website at www.mbconnectline.com.
Hereby MB CONNECT LINE acknowledges that the
device mbSECBOX (MDH874) is in complies with the
essential requirements and other relevant
provisions of directive 1999/5/EC. The declaration of
conformity can be found at:
www.mbconnectline.com
Publisher:
MB connect line GmbH
Fernwartungssysteme
Winnettener Str. 6
91550 Dinkelsbühl
Germany
+ 49 (0) 700 / MBCONNECT
+ 49 (0) 700 / 62 26 66 32
www.mbconnectline.com
Copyright © MB Connect Line GmbH 2014
