Double Mount Installation - V-AW12BLP / V-AW16BLP

Included in Mounting Kit (A-SLM-MK-S-1)

Description

Mounting Piece

#6-19x7/16 screw

Strain relief

Included in Wiring Kit (A-WK-12-1V)

Power/grounding wires

And connector

#8x1.5 Self-tapping screw

Wall anchor

Included in Gang Box Kit (A-GB-MK-1)

#6-32x1 screw

#6-19x3/8 screw

PLEASE NOTE: A user will also have to provide a Phillips-head screwdriver, a small flat-blade screwdriver, a drill with a 1/4 inch drill bit, a pencil, a double

gang box, four wall anchors (must support 50 lbs, #8 screw size, 1.5"(3.8cm) screw length), four #8 screws for the wall anchors, any equipment needed to

install the gang box, and any additional wiring needed to extend the power or ground cables.
