Wall Mount Installation - V-AW12A / V-AW16A
5) Place the cover back onto the battery pack. You
should hear a snapping noise as the locking tab
engages. Use the #4x5/16 Screw screw to prevent
the cover from opening again.
7) Align the peg on the top portion of the mounting bracket with the hole on top of the clock case. Slide
the peg through the hole. Use the bracket securing nut to secure the peg in place.
5 6
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
6) Slide the long, protruding part of the mounting
bracket into the clock case keyhole.
P. 540-563-2000
F. 540-362-9800
www.valcom.com
7
10
