Valcom V-AW12A Installation Manual page 21

Flag Mount Installation - V-AW12A / V-AW16A
INSTALL, POWER, AND SET YOUR MASTER CLOCK OR REPEATER BEFORE POWERING THE SECONDARY
WIRELESS CLOCKS
A Valcom Master Clock and any Repeaters must be installed, powered, and set up BEFORE you attempt to set up a wireless clock system. If
the Master Clock and Repeaters are not properly installed and powered, the secondary clocks will not synchronize.
Included in Package
Description
V-AW12A/V-AW16A or Standard
ABS analog clock
Included in Wiring Kit (A-WK-12-1)
Mounting Bracket
#10x1.5 Self-tapping screw
Wall anchor
#4x5/16 Screw
Bracket Securing Nut
If any of the items listed in the kits are missing, you may contact Valcom and order a replacement kit.
VERY IMPORTANT:
Quantity
1
1 (not used)
2 (not used)
2 (not used)
1 (not used)
1
(not used)
Continued on next page
