Valcom V-AW12A Installation Manual page 56

Wireless analog clock
Hide thumbs Also See for V-AW12A:
Table of Contents

Advertisement

11 12
Double Mount Installation - V-AW12LP / V-AW16LP
11) First remove the gearbox pins, then attach the
power connector to the port on each movement.
2
Later models of this clock use the same movements as the B-Model
version of the same type. For instructions on how to set up the
B-model movement, refer to the B-model section of this manual for
the same type of clock.
13
13) If you feel the need to detach the clock
from the housing after the installation has been
completed, remove the outer adapter screws, press
down on the latches, and gently pull on the rim of
the clock until the clock detaches.
1
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
12) Remove the outer adapter screws, then slide
each clock onto the adapter in the rotation that you
wish it to be viewed. You should hear a snapping
noise as the four clips on the adapter secure the
clock in place. Insert the screws again to complete
the installation.
P. 540-563-2000
F. 540-362-9800
www.valcom.com
56
