Valcom V-AW12A Installation Manual page 57

Double Mount Installation - V-AW12B / V-AW16B
INSTALL, POWER, AND SET YOUR MASTER CLOCK OR REPEATER BEFORE POWERING THE SECONDARY
WIRELESS CLOCKS
A Valcom Master Clock and any Repeaters must be installed, powered, and set up BEFORE you attempt to set up a wireless clock system. If
the Master Clock and Repeaters are not properly installed and powered, the secondary clocks will not synchronize.
Included in Package
Description
V-AW12B/V-AW16B round
SlimLine analog clock
Included in Double Mount Kit (V-WDM-12 or SV-WDM-16)
Dual-mount pole, including
mounting plate.
#10-32x3/8 green screw
#8-32x7/16 screw
M3.5-1.0x10 screw (black)
Internal-tooth washer
#6-32x1 screw
If any of the items listed in the kits are missing, you may contact Valcom and order a replacement kit.
VERY IMPORTANT:
Quantity
2
1
1
8
4
8
4
Continued on next page
